DLP® LightCrafter™ E3010LC - 3D Printing UV


EKB's DLP® E3010A Light Control evaluation module (EVM) is an easy-to-use evaluation platform for a wide variety of industrial applications like 3D scanning, 3D printing, medical imaging, automated optical inspection (AOI) and facial recognition.


$1499 $1799(-16.68%)
  • SKU: DPM-E3010LCUV
  • Shipping:

AC Adapter: *
BNC trigger cable adapter : *

Learn More



  DLP® E3010A-LC  evaluation module (EVM) is an easy-to-use evaluation platform for a wide variety of industrial applications like 3D scanning, 3D printing, medical imaging, automated optical inspection (AOI) and facial recognition. It supports two configurable input triggers and one configurable output trigger to allow convenient synchronization with cameras, sensors, or other peripheral devices. The EVM features a DLP3010 (.3 720p, 1280x720) digital micromirror device (DMD), a DLPC3478 display and light controller and a DLPA3000 PMIC/LED driver. It comes a production ready Projector and offers a compelling combination of resolution, brightness, speed and programmability in a small form factor.


Features
  • Pixel Accurate 3D printing Via HDMI(Bypass video algorithm for advanced pixel precision)
  • DLP3010, DLP .3 720p(1280x720) DMD
  • DLPC3478, Digital Controller for the DLP3010 DMD
  • DLPA2005, PMIC/LED Driver for the DLP3010 DMD and DLPC3478 controller
  • Production ready UV LED optical engine from EKB Technologies
  • Offset 0%(On Axis projection); output power: 0.5W; Contrast Ratio: 500:1
  • Uniformity 95%; Distortion <1% ; Exposure Field: 128mm X 72mm
  • Working Distance: 147.6mm ; Throw Ratio: 1.15
  • Up to 2500 Hz binary pattern rate
  • Up to 130 Hz 8-bit gray scale pattern rate
  • DLP3010, DLPC3478 Configuration and Support Firmware

What's Included


  • DLP3010, DLP .3 720p(1280x720) DMD
  • DLPC3478, Light Control Controller for the DLP3010 DMD
  • DLPA2005, PMIC/LED Driver for the DLP3010 DMD and DLPC3478 controller
  • Production ready UV 405nm optical engine from EKB Technologies  500mw off lens projection.
